• Lightweight ULTRA-COMPACT ergonomic design at only 117 mm long
• Dual LED lights with pre-glow and afterglow functions illuminate the work area more widely
• T-mode has an automatic electronic controller that downshifts and reduces rotation and impact speed prior to driving screw into place, and is designed to minimize screw thread stripping, screw breakage etc.
• Brushless motor delivers 3,600 Max RPM and 175 N·m (1,550 in.lbs.) of Max Torque
• 3-Speed power selection switch (0-1,100 / 0-2,100 / 0-3,600 RPM & 0-1,100 / 0-2,600 / 0-3,800 IPM) provides the user with precise fastening control for a wide range of applications
• Water-resistance compatible with XPT
• Electric brake for maximum productivity and increased operator safety
• Reverse switch is conveniently located
• Durable, reversible belt clip convenient for temporary tool hanging
• Battery protection circuit protects against overloading, over-discharging and over-heating
Buy From Retailer
| Capacity | Machine screw: M4 – M8 (5/32 – 5/16″) High strength bolt: M5 – M14 (3/16 – 9/16″) Steel: 22 mm (7/8″) |
Standard bolt: M5 – M16 (3/16 – 5/8″) Coarse thread (in length): 22 – 125 mm (7/8 – 4-7/8″) Wood (Auger bit): 24 mm (15/16″) |
|---|---|---|
| Hole saw diameter | 38 mm (1-1/2″) | |
| Hex shank | 6.35 mm (1/4″) | |
| Shank / Drive | Hex Shank 6.35 mm (1/4″) | |
| Max fastening torque | 175 N·m (1,550 in.lbs.) | |
| No load speed | Hard / Med. / Soft: 0 – 3,600 / 0 – 2,100 / 0 – 1,100 minˉ¹ | |
| Impacts per minute | Hard / Med. / Soft: 0 – 3,800 / 0 – 2,600 / 0 – 1,100 minˉ¹ | |
| Vibration level | Impact tightening of fasteners of the maximum capacity of the tool: 12.5 m/s² | |
| Vibration K factor | Impact tightening of fasteners of the maximum capacity of the tool: 1.5 m/s² | |
| Sound pressure level | 96 dB(A) | |
| Sound power level | 107 dB(A) | |
| Noise K factor | 3 dB(A) | |
| Dimensions (L × W × H) | 117 x 79 x 236 mm (4-5/8 x 3-1/8 x 9-1/4″) | |
| Net weight | 1.3 – 1.6 kg (2.7 – 3.4 lbs.) | Battery dependent |
